SEMI HEIGHT OPTICAL FLAP TURNSTILE MT246
We can provide OEM and ODM services. We have experienced designers who can complete deep customization according to any of your needs. We will provide a series of materials such as 3D renderings, dimensional drawings, etc. as soon as possible.
Optical flap turnstile is an upgraded version with higher security than the regular flap barrier turnstile, which has a unique design, beautiful and fashionable appearance, more stable and silent operation, and has anti tailgating function, suitable for use in high-end places.
All of our products carry a 2 years warranty and durable maintenance and repair support. We also provide biometric devices, such as fingerprint scanner, face recognition camera. RFID card reader, QR code scanner. If you need to integrate these devices on the turnstile gate or have any questions, please request a quote.
We can also create a rendering for you within a few minutes based on your actual scenario. We also provide detailed layout and drawings, as well as installation drawings. Let you have no worries about installation. Please download our corresponding PDF file for specific dimensions and installation dimensions.
Technical Parameter:
1. Size: 1400*350*1000 mm (can be customized)
2. Lane width: 600 mm (can be customized)
3. Passing speed: 40 person/min
4. Power supply: 110V/220V 50/60Hz
5. Driving Motor: 30W/40W
6. Gate Open Signal: Dry Contact/ Relay
7. Driving Motor: DC24V
8. Optical flap turnstile weight: 70 kg/pcs
9. Arm height: 1200 mm
10. Arm material: acrylic/tempered glass
11. Top Cover: Marble
12. Casing Material: 304 stainless steel
13. Reliability of the mechanism: 3 million-5 million, no-fault
14. Lane width 900 mm can be customized
15. Arm height can be added to 1800 mm
16. Size and material thickness can be customized
17. Working Direction: Bidirectional/Single directional
18. Emergency situation: open automatically when the electricity is cut off with a capacitor
19. Humidity: ≤90％20. Working temperature: -20℃～60℃
21. Communication distance: ≤1200 m
22. Communication interface: RS485
23. Feature: IC/ID reader, Barcode Reader, Face recognition, Fingerprint, other access control equipment, UPS, etc
24. Optical flap turnstile opening time: 0.2 s
25. Working Environment: Indoors
26. Application range: Community, Factory, Construction site, School, Place of the resort, etc
We can provide the entire security access control solution. If you have your own access control system, you can directly use our optical flap turnstile gate. If you don’t have one, we also provide a complete security access control solution. Please refer to the video below for details.
